Ibis Mojo V4 NGX

Ibis Mojo V4 NGX
  • Color: Blue Dream
  • Color: Dirty White Board
$6,799.00
Color:
Dirty White Board
Size:
Medium
Wheelset:
Ibis S35 Carbon I9 XD
Please select options

Details

The word Mojo refers to a magic spell or charm, and more broadly, a magical power. Since its introduction in 1994, the Mojo has delivered a wicked combination of fun and all-mountain prowess.

GEOMETRY
The Mojo V4 fea­tures a 76.6-degree, get-you-up-that-hill seat tube angle, our short­est chain­stays, and a spa­cious reach with a 65.4-degree head­tube angle. This enchant­i­ng com­bi­na­tion rolls on 27.5" wheels to deliv­er that hov­er­bike feel with on-trail confidence.

DW-LINK
Since 2005, we've part­nered with sus­pen­sion guru, Dave Weagle, on the dw-link sus­pen­sion plat­form. It pro­vides an unpar­al­leled com­bi­na­tion of climb­ing effi­cien­cy and down­hill per­for­mance, which has been proven repeat­ed­ly at the high­est lev­els of racing.

TRACTION TUNE
Our cus­­tom-tuned sus­pen­sion fea­tures extra-light high-speed com­pres­sion and rebound damp­ing to deliv­er unpar­al­leled trac­tion. When paired with our dw-link sus­pen­sion plat­form, Trac­tion Tune allows the Mojo to track like a big bike with­out com­pro­mis­ing crisp ped­al­ing per­for­mance.

PICK YOUR SIZE
All four sizes have low stan­dover heights and short­ened seat tubes for long drop­per posts. Now you can choose your frame based on reach-rid­ers 5-feet tall eas­i­ly fit on a small and still enjoy a 125mm drop­per, while most medi­um and up rid­ers can enjoy a 185mm. All sizes fit a water bot­tle, and those look­ing to go packless can run our after­mar­ket Pork Chop bag.

FORK OFFSET
Reduced-off­set forks give the front wheel greater sta­bil­i­ty at speed and an addi­tion­al sense of steadi­ness at slow speeds too. The Mojo is designed to excel in tech­ni­cal, demand­ing ter­rain, and the 37mm-off­set gives that extra bit of con­fi­dence and con­trol in the most chal­leng­ing situations.

TIRE CLEARANCE
The Mojo has clear­ance for 27.5"x2.6" tires. You can run over­built, chunky tires; you can run light, big vol­ume fast tires, but what­ev­er you run, know that you're not lim­it­ed by width.

BUSHINGS
Tired of hit­ting "pur­chase" on anoth­er set of bear­ings each sea­son? So were we. That's why we use bush­ings where they make sense, and bear­ings where they don't. The IGUS bush­ings in our low­er link are lighter and stiffer than bear­ings and are vir­tu­al­ly main­te­nance-free. We believe so strong­ly in them, we back them with a free life­time replacement.

LIGHTWEIGHT PREMIUM CARBON FOR EVERYONE
All our bikes are built from the high­est-grade mate­ri­als and opti­mized for the best strength, weight, stiff­ness, and ride per­for­mance-no mat­ter how much you spend. The Mojo weighs a svelte 5.9 lbs with an inline shock, and com­plete builds start at 26.7 lbs.

INTERNAL CABLE ROUTING
Bikes that look pret­ty on the out­side should look pret­ty on the inside. We use car­bon fiber tubes mold­ed with­in each frame. Push the cable in, watch it pop out, a beau­ti­ful moment indeed.

REMOVABLE ISCG MOUNT
There if you want it, remov­able if you don't.

PROTECT YOUR INVESTMENT
A poly­car­bon­ate down­tube pro­tec­tor deflects debris, while mold­ed rub­ber swing arm pro­tec­tors keep things qui­et and clean. And, our sim­ple-yet-ele­gant link­age pro­tec­tors stop mud and rocks thrown by the tire, keep­ing your beau­ti­ful bike beautiful.

bike frame with labeled dimensions
Bike Sizes:
SmallMediumLargeX-Large
A. Reach 440mm 460mm 485mm 515mm
B. Stack 586mm 601mm 616mm 630mm
C. Standover 680mm 690mm 720mm 742mm
D. Effective Top Tube 580mm 603mm 632mm 666mm
E. Head Tube Angle 65.4° 65.4° 65.4° 65.4°
F. Head Tube Length 109mm 126mm 142mm 158mm
G. Seat Tube Angle 76.6° 76.6° 76.6° 76.6°
H. Seat Tube Length 360mm 368mm 419mm 470mm
I. Bottom Bracket Height 340mm 340mm 340mm 340mm
L. Trail 123mm 123mm 123mm 123mm
M. Wheelbase 1166mm 1193mm 1225mm 1262mm
O. Chainstay Length 425mm 425mm 425mm 425mm
Sizes:
Small 152–165CM
Medium 163–175CM
Large 173–185CM
X-Large 183–198CM

Specs

Frame Mojo 4
Fork Rock Shox Pike Ultimate RC2 140mm, 27.5", 110x15
Rear Shock Fox Float Factory Series, DPS with EVOL, 210 x 50 S/M: Light Tune, L/XL: Standard
Wheels Select from the dropdown above
Tires Front: Schwalbe Hans Dampf 27.5 x 2.6" Addix Soft Super Trail
Rear: Schwalbe Nobby Nic 27.5 x 2.6" Addix Speedgrip Super Trail
Bottom Bracket SRAM DUB BSA
Crankset SRAM NX Eagle DUB, 30t Alloy Ring, S/M: 170mm, L/XL: 175mm
Shifters SRAM NX Eagle
Rear Derailleur SRAM GX Eagle
Cassette/Freewheel SRAM XG 1275, 10-52t
Chain SRAM NX Eagle
Brakes SRAM G2 R 4p
Rotors SRAM Centerlock, 180mm
Handlebars Ibis 780mm Alloy
Tape/Grips Lizard Skin Charger
Stem Ibis 31.8mm S/M: 40mm, L/XL: 50mm
Headset Cane Creek 40 ZS44/ZS56
Seatpost KS Rage-i Dropper S: 125mm, M: 150mm, L/XL: 170mm
Saddle WTB Silverado 142
Pedals Sold separately

* Subject to change without notice.
